BUSHING
INFORMATION
ALL ELECTRICAL RATINGS ARE BASED ON PORCELAIN SHANKS
BEING UNDER OIL IN ACCORDANCE WITH TRANSFORMER INDUSTRY STANDARDS AND GOOD
DESIGN PRACTICE. ALL STATEMENTS, TECHNICAL INFORMATION, DATA, AND
RECOMMENDATIONS IN THIS CATALOG ARE BASED ON TESTS WE BELIEVE TO BE
RELIABLE; BUT THE ACCURACY THEREOF IS NOT QUARANTEED AND NO WARRANTIES ARE
IMPLIED. THE CUSTOMER IS TO DETERMINE THE SUITABILITY OF OUR ITEMS FOR THIS
EQUIPMENT BY HIS OWN TESTS.
PORCELAIN INSULATORS
ALL PORCELAIN MEETS
APPLICABLE ANSI, AND IEEE STANDARDS AND DRAWING REQUIREMENTS, AND IS OF THE
FINEST ELECTRICAL GRADE GLAZED ASA GRAY.
CONNECTORS
CONNECTORS ARE OF
ELECTRICAL BRONZE AND ARE TIN PLATED, SLIVER PLATING AVAILABLE UPON REQUEST.
CONDUCTORS
STUDS & BUSS
- #110 ALLOY COPPER
WIRE
- #4, #6, #8, #10 AWG. STRANDED
GASKETS
STOCKED MATERIAL:
BUNA (NITRILE), CORKPRENE (ARMSTRONG
711), VITON, VEGITABLE FIBER (PAPER).
CLAMPS & FLANGES
STANDARD CLAMPS & FLANGES ARE MADE FROM HIGH STRENGTH ALUMINUM CASTINGS.
BRASS IS ALSO AVAILABLE UPON SPECIAL REQUEST.
